ASME B16.34 Needle Globe Valve, 3/4 Inch, 5000 PSI
ASME B16.34 Needle Globe Valve Provider: Needle Type Globe Valves, ASME B16.34, ASTM A182 F304, 3/4 Inch, DN20, 5000 PSI, Socket Weld.
- Categories
- Globe Valves
- Tags
- Needle Type Globe Valves , ASME B16.34 Globe Valves , Forged Steel Globe Valves
Detail Information
ASME B16.34 Needle Valve
Name: Forged Globe Valve
Size: 3/4 Inch, DN20
Pressure: 5000 PSI
Standard: ASME B16.34
Material: ASTM A182 F304
Seal material: Gasket
Connection form: Socket Weld
Media: Oli, Gas, Water
Power: Manual, Pneumatic, Solenoid, Electrical Actuated
Temperature Of Media: Medium Temperature, Normal Temperature, High Temperature, -65℉ To 450℉ (-54℃ To 232℃)
Product Range
Size: 1/4 Inch-4 Inch, DN8-DN100
Pressure: Class 800 to Class 2500
Materials: Available in Forged A105, ASTM A350 LF2, ASTM A182 F5, ASTM A182 F11, ASTM A182 F22, ASTM A182 F304, ASTM A182 F304L, ASTM A182 F316, ASTM A182 F316L, ASTM A182 F347, ASTM A182 F321, ASTM A182 F51, Alloy 20, Monel, Inconel, Hastelloy
Standard: API 602, BS 5352, GOST, JIS, DIN, ISO
Certification: ISO 9001, ISO 14001, ISO 18001, CE, TS
Name: Forged Globe Valve
Size: 3/4 Inch, DN20
Pressure: 5000 PSI
Standard: ASME B16.34
Material: ASTM A182 F304
Seal material: Gasket
Connection form: Socket Weld
Media: Oli, Gas, Water
Power: Manual, Pneumatic, Solenoid, Electrical Actuated
Temperature Of Media: Medium Temperature, Normal Temperature, High Temperature, -65℉ To 450℉ (-54℃ To 232℃)
Product Range
Size: 1/4 Inch-4 Inch, DN8-DN100
Pressure: Class 800 to Class 2500
Materials: Available in Forged A105, ASTM A350 LF2, ASTM A182 F5, ASTM A182 F11, ASTM A182 F22, ASTM A182 F304, ASTM A182 F304L, ASTM A182 F316, ASTM A182 F316L, ASTM A182 F347, ASTM A182 F321, ASTM A182 F51, Alloy 20, Monel, Inconel, Hastelloy
Standard: API 602, BS 5352, GOST, JIS, DIN, ISO
Certification: ISO 9001, ISO 14001, ISO 18001, CE, TS
